DHB 13 Inch Taxi Headrest Advertising Display

Ultra HD Display for Premium Fleet Advertising

The DHB 13 Inch Taxi Headrest Advertising Display is a premium in-vehicle digital signage solution developed by Shenzhen Donghebao Technology Co., Ltd. for taxi advertising, ride-hailing fleets, passenger information systems, and smart transportation projects. Designed for customers seeking exceptional display quality and a larger viewing experience, it combines advanced Android performance with ultra-high-definition display technology.

Powered by the RK3566 quad-core ARM Cortex-A55 64-bit processor and Android 11, the display provides stable multimedia playback, smooth application performance, and flexible integration with fleet management platforms. It is available with 2GB + 32GB or 4GB + 64GB memory configurations to support both standard and large-scale commercial deployments.

The 13 Inch Taxi Headrest Advertising Display features a premium G+G IPS LCD panel with optional 2660 × 1440 (2K) or 1920 × 1280 resolution and a 16:10 aspect ratio. Compared with conventional Full HD displays, the larger screen and higher resolution deliver sharper images, richer colors, and more detailed advertising content, making it an ideal choice for luxury taxi fleets, executive ride-hailing vehicles, and premium digital media projects.

To support modern fleet operations, the display offers Bluetooth, 2.4GHz Wi-Fi, optional dual-band Wi-Fi (2.4GHz + 5GHz), an optional European 4G LTE module, and external GPS for reliable connectivity and location-based services. Optional Cloud CMS integration enables remote advertising updates, centralized device management, media scheduling, and real-time fleet monitoring.

The DHB 13-inch model also supports optional 5MP external camera, microphone, capacitive touch screen, PIR human detection, light sensor, anti-glare glass, screen rotation, and 24W fast charging. Ambient light adjustment with 256-level brightness control ensures excellent visibility under varying lighting conditions, while the adjustable viewing angle enhances passenger comfort.

Designed specifically for commercial vehicle environments, the display operates with a DC input voltage of 9V–16V, supports a maximum working current of 3A, and measures 289 × 204 × 29 mm, making it suitable for installation in a wide range of taxis, ride-hailing vehicles, and executive fleets.

With complete OEM & ODM services, including custom branding, firmware development, Android customization, CMS API integration, vehicle-specific mounting brackets, and packaging design, the DHB 13 Inch Taxi Headrest Advertising Display provides a reliable and scalable solution for global fleet media and taxi advertising projects.

Technical Specifications

Item	Specification
Product Model	DHB 13 Inch
Display Size	13 Inch
Operating System	Android 11
Chipset	RK3566
CPU	ARM Cortex-A55 64-bit Quad-Core
Display Panel	G+G IPS LCD
Resolution	Optional 2660 × 1440 (2K) / 1920 × 1280
Aspect Ratio	16:10
Memory	2GB + 32GB / 4GB + 64GB
Bluetooth	Supported
Wi-Fi	2.4GHz / Optional Dual-Band 2.4GHz + 5GHz
4G Module	Optional European LTE (FDD: B1/B3/B5/B7/B8/B20/B28, TDD: B38/B40/B41)
GPS	Optional External GPS
Camera	Optional External 5MP Camera
Microphone	Optional
Touch Screen	Optional Capacitive Touch
PIR Human Detection	Optional
Ambient Light Adjustment	Supported (256-Level Brightness Control)
Light Sensor	Optional
Anti-Glare Glass	Optional
Screen Rotation	Optional
Viewing Angle	Adjustable
Fast Charging	24W USB Fast Charging
Input Voltage	DC 9V–16V
Maximum Working Current	3A
DC Input	Supported (Optional Cigarette Lighter Power Supply)
Overall Dimensions	289 × 204 × 29 mm
Cloud CMS Platform	Optional

Why Choose the DHB 13 Inch?

Key Benefits

Premium 13-inch G+G IPS display
Optional 2K (2660 × 1440) ultra-high-definition resolution
Optional 1920 × 1280 resolution
16:10 aspect ratio for enhanced advertising visibility
RK3566 quad-core processor
Android 11 operating system
Optional Cloud CMS integration
Optional 4G LTE and external GPS
24W fast charging
Support for external camera, microphone, PIR sensor, and light sensor
OEM & ODM customization
Professional technical support

Contact Us

Start Your Taxi Headrest Advertising Display Project Today

Looking for a reliable manufacturer of Taxi Headrest Advertising Displays?

Whether you need a standard 13 Inch Taxi Headrest Advertising Display or a fully customized in-vehicle advertising solution, Shenzhen Donghebao Technology Co., Ltd. provides professional OEM & ODM manufacturing, Cloud CMS integration, hardware customization, and technical support for customers worldwide.
